RF & Microwave
Data Patterns has a strong RF and Microwave engineering capability, featuring a team of enthusiastic engineering talent, substantial investments in RF test and measuring instruments, and attitude to utilise the latest technologies.
An in-house manufacturing capability and an insatiable demand for fulfilling requirements of Radar, Electronic Warfare and Communication domains, Data Patterns has developed a whole line of building blocks including TR Modules, Up and Down Converters, Power Amplifiers, Transmitters, Combiners and Dividers for specific requirements. A list of products is given below.
| Product Name | Description | View |
|---|---|---|
| DP-CRF-0500 | DDS Piggy Module, 250 to 660 MHz, BMA Female connector (Wideband, Custom) |  |
| DP-CRF-2303 | Local Oscillator 2 Module 1.44/1.56 GHz, BMA female Connector (L band, Local Oscillator) | |
| DP-CRF-2309 | Local Oscillator 2 Module 1560MHz (L Band, Local OScillator) | |
| DP-CRF-2312 | Local Oscillator 1 Module 7370 to 7970 MHz (C Band, Local Oscillator) | |
| DP-CRF-2315 | Rugged, LO1 & LO2 Module for Primary surveillance Radar | |
| DP-CRF-2501 | 5kW High Power SPDT Switch | |
| DP-CRF-2504 | 4 KW Power Amplifier Front End Driver Module | |
| DP-CRF-2507 | High power Microstrip Low pass Filter for 1KW Transponder Transmitter | |
| DP-CRF-2510 | Front End Driver Board for Transponder Transmitter | |
| DP-CRF-2513 | 1KW Transmitter with SPDT Switch for Transponder | |
| DP-CRF-3407 | Monopulse Comparator - LLTR Ashwini Array - 3.1 to 3.5GHz | |
| DP-CRF-3503 | Commercial,RF Adapter Module to test AGRU Tx Drive Distribution SRU | |
| DP-CRF-3506 | Commercial, RF Adapter module to test DTRM Rx SRU | |
| DP-CRF-4502 | OCXO Module 30MHz SMA Female connector | |
| DP-CRF-4508 | C Band,X Band Micro Strip Filters | |
| DP-CRF-4511 | C Band,X Band Micro strip Power divider and Coupler-50 Ohm | |
| DP-CRF-4514 | 30Mhz to 500MHz Directional Coupler Forward power matching network module | |
| DP-CRF-4517 | 30Mhz to 500MHz Directional Coupler Reverse power Matching network module | |
| DP-CRF-4520 | 60MHz OCXO Module, Custom | |
| DP-CRF-4523 | BITE Module, 9 GHz to 9.8 GHz | |
| DP-CRF-4526 | Band Pass filter Test Board - 9 GHz to 9.8 GHz | |
| DP-CRF-4529 | 10 MHz, 10 ppb, 13 dBm OCXO Module | |
| DP-CRF-5000 | Calibration Power Divider 1:14, 3.1 to 3.5 GHz, QMA Female connector | |
| DP-CRF-5003 | Transmit Divider 1:6, 3.1 to 3.5 GHz, QMA Female connector. | |
| DP-CRF-5006 | Transmit Divider 1:4, 3.1 to 3.5 GHz, QMA Female connector. | |
| DP-CRF-5009 | LO1 Divider 1:6, 2.5 to 2.9 GHz, QMA Female connector | |
| DP-CRF-5012 | LO1 Divider 1:4, 2.5 to 2.9 GHz, QMA Female connector | |
| DP-CRF-5015 | LO2 Divider 1:6, 540 Mhz, QMA Female connector | |
| DP-CRF-5018 | LO2 Divider 1:4, 540 Mhz, QMA Female connector | |
| DP-CRF-5021 | Master Clock Divider 1:6, 50 MHz, QMA Female connector | |
| DP-CRF-5024 | Master Clock Divider 1:4, 50 MHz, QMA Female connector | |
| DP-CRF-5027 | Calibration Switch - 1:2 - 3.1 to 3.5GHz - QMA Female connector | |
| DP-CRF-5033 | Cascaded 6-17GHz Amplifier with 15GHz Low Pass Filter Integrated Module | |
| DP-CRF-5036 | 6-26GHz Mixer with 6-17GHz LO Amplifier Integrated Module | |
| DP-CRF-5039 | Radiating Segment - Antenna Panel (8x8) - 3.1 to 3.5GHz - BMA Female Connector | |
| DP-CRF-5042 | Radiating Segment - Antenna Panel (6x8) - 3.1 to 3.5GHz - BMA Female Connector | |
| DP-CRF-5048 | 8-Way Power Combiner - 3.1 to 3.5GHz - QMA Female connector | |
| DP-CRF-5051 | 6-Way Power Combiner - 3.1 to 3.5GHz - QMA Female connector | |
| DP-CRF-5054 | Radiating Segment - Antenna Panel (8x8) - 3.1 to 3.5GHz - BMA Female Connector along with QMA Termination for CAL LINES | |
| DP-CRF-5057 | Radiating Segment - Antenna Panel (6x8) - 3.1 to 3.5GHz - BMA Female Connector along with QMA Termination for CAL LINES | |
| DP-CRF-5060 | L-Band 70 MHZ to 950-1700MHz Up Conversion Module | |
| DP-CRF-5063 | L-Band 950-1700MHz to 140 MHz Down Conversion Module | |
| DP-CRF-5066 | L Band Clock Generation Up Down conversion Controller Module | |
| DP-CRF-5102 | Transmitter Drive Module,9GHz to 9.8GHz, BMA Female Connector | |
| DP-CRF-5105 | LTCC Based X Band TR Module | |
| DP-CRF-5108 | X Band TR Module Plank Controller Type 1 | |
| DP-CRF-5111 | X Band 8W TR Module on Ceramic PCB Type 2 | |
| DP-CRF-5114 | RF Test Board for X band TR Module | |
| DP-CRF-5117 | X Band 8W TR Module on Ceramic PCB Type 3 |  |
| DP-CRF-5120 | X Band 100W Solid State Power Amplifier, Pin : 25 dBm | |
| DP-CRF-5204 | IF1 Down Converter Module,1620MHz/1630MHz, BMA Female Connector | |
| DP-CRF-5207-600 | IF2 Down Converter Module, 180MHz/70MHz, BMA Female Connector | |
| DP-CRF-5207-630 | Rugged,Single channel IF2 Down Converter Module,70 MHz for Primary Surveillance Radar | |
| DP-CRF-5210 | Radiating Element - 2x2 Antenna Panel | |
| DP-CRF-5300-VER | Local Oscillator Module,7.37 to 8.18 GHz BMA male connector (C Band, Local Oscillator) | |
| DP-CRF-5303-VER | Calibration and Spurious/Image Frequency Rejection Module, 1620/1630MHz, BMA Male connector | |
| DP-CRF-5306 | 1:3 LO1 Distribution Module 7.370GHz to 8.180GHz SMA Input and SMP output Connector | |
| DP-CRF-5402 | Solid State Amplifier Module (X Band, Power Amplifier) | |
| DP-CRF-5405 | Imaging and Monopulse Antenna Panel - 9 GHz to 9.8 GHz - 300W-SMA,TNC female connector | |
| DP-CRF-5408 | 1:3 Power Divider Module - 9 GHz to 9.8 GHz - SMA female connector | |
| DP-CRF-5411 | Rugged Wide Band VHF/UHF RF Tuner (down converter) for WBSPU | |
| DP-CRF-5414 | Rugged three channel HF Tuner (2 -30MHz) | |
| DP-CRF-5417 | S-Band 0.5W Amplifier Module | |
| DP-CRF-5420 | Rugged HF RF Tuner (down converter) for Search Receiver | |
| DP-CRF-5423 | Dual Quadrature Combiner Module for BPA | |
| DP-CRF-5426 | Dual Quadrature Divider Module for BPA | |
| DP-CRF-5429 | In Phase 4:1 Combiner Module for Power Amplifier | |
| DP-CRF-5432 | In Phase 1:4 Divider Module for Power Amplifier | |
| DP-CRF-5435 | 4 KW Power Amplifier Module | |
| DP-CRF-5438 | 3.5 KW Power Amplifier Module | |
| DP-CRF-5441 | 2.5 KW Power Amplifier Module | |
| DP-CRF-5444 | 1.5 KW Power Amplifier Module | |
| DP-CRF-5447 | 800W Power Amplifier Module, 1090MHz | |
| DP-CRF-5450 | 4Way Hybrid Power Divider | |
| DP-CRF-5453 | 8 Way Hybrid Power Divider | |
| DP-CRF-5456 | 4Way Hybrid Power Combiner | |
| DP-CRF-5462 | 1kW Power Amplifier Module | |
| DP-CRF-5465 | 1:2 RF & IF Distribution Module with Status output for LLTR CU | |
| DP-CRF-5468 | High power Directional coupler - 9 GHz to 9.8 GHz -300watts Peak & 60 watts Avg power | |
| DP-CRF-5471 | U/VHF Wideband IF Filter Module | |
| DP-CRF-5474 | Test board for 120W GaN Power Amplifier Module | |
| DP-CRF-5483 | 400MHz DDS synthesizer module | |
| DP-CRF-5486 | L-Band 950-2050 MHz Transceiver Module | |
| DP-CRF-5489 | 18GHz Tuner Sub circuits | |
| DP-CRF-5492 | X Band 100W Solid State Power Amplifier Module | |
| DP-CRF-5495 | C Band & X Band Filters Test board | |
| DP-CRF-5498 | X Band 4X100W Solid State Power Amplifier, Pin : 40dBm | |
| DP-CRF-5501 | Receiver Front End Module,9GHz to 9.8GHz, BMA Female Connector | |
| DP-CRF-5504 | PLL Based HF to S Band Programmable Signal Source | |
| DP-CRF-5507 | RF Front End For Down-Link Module (Mating connector option) | |
| DP-CRF-5510 | HF 2 to 30MHz Signal Distribution Unit | |
| DP-CRF-5513 | RF Front end module for UP-Link 1643.5 +/- 17Mhz, -106 dBm Rx Sensitivity, 73 dB Rx Gain,TNC connector | |
| DP-CRF-5516 | Single channel X-band Receiver Front End Module,SMA Female connector | |
| DP-CRF-5519 | X Band Dual Quadrature power divider / combiner | |
| DP-CRF-5522 | 2kW Power Amplifier, 1030 MHz/ 1090 MHz, Pin:44dBm | |
| DP-CRF-5525 | Driver Amplifier, 1030 MHz/ 1090 MHz, Pin:10 dBm, Pout:44dBm | |
| DP-CRF-5528 | Pre Driver Amplifier, 1030 MHz/ 1090 MHz, Pin:10 dBm, Pout:27dBm | |
| DP-CRF-5531 | 25W Power Amplifier, 1030 MHz/ 1090 MHz, Pin:23 dBm, Pout:44dBm | |
| DP-CRF-5534 | 2 Way Hybrid Power Divider, 1030MHz/1090MHz, IL: 0.5dB (Max) | |
| DP-CRF-5537 | 2 Way Hybrid Power Combiner, 1030MHz/1090MHz, IL: 0.6dB(Max) | |
| DP-CRF-5540 | 2.5kW SPDT Switch , 1030MHz, IL:0.6dB(Max), Isolation: 25dB (Min) | |
| DP-CRF-5543 | Dummy Transmission line Board for for 2kW IFF Power Amplifier | |
| DP-CRF-5546 | X Band Quadrature Coupler Power Divider | |
| DP-CRF-5549 | VHF/UHF Tranceiver module for CubeSat with PC104 Interface | |
| DP-CRF-5552 | S-Band Transmitter module for CubeSat with PC104 Interface | |
| DP-CRF-5558 | CIT Receiver Module | |
| DP-CRF-5561 | 20-1000MHz VUHF Tuner - Down converter for Search Receiver, 76.8MHz IF, 40MHz BW | |
| DP-CRF-5564 | 20 to 1000MHz VUHF Tuner - Synthesizer, Controller & BITE | |
| DP-CRF-5567 | 1.5 to 30MHz HF Tuner | |
| DP-CRF-5570 | 20 to 1000 MHz. Exciter- Synthesizer & Controller | |
| DP-CRF-5573 | 20 to 3000MHz Exciter - Up Converter | |
| DP-CRF-5576 | Antenna Switching Module for IFF Transponder , 1090MHz , Pin: 60dBm, IL:1.8dB(Max), Isolation:20dB (Min) | |
| DP-CRF-5579 | Rugged,X Band (9.3-9.5 GHz) Digital Attenuator Module,SMA Female Connector for Primary Surveillance Radar | |
| DP-CRF-5582 | 20 to 1000MHz VUHF Tuner - Front End | |
| DP-CRF-5585 | 12.8GHz LO Generation & Controller Module for Ku Band Up Converter | |
| DP-CRF-5615 | S-Band Transmitter | |
| DP-CRF-6002 | VHF Master Combiner Module | |
| DP-CRF-6005 | Digital calibration & IF2 Module of Imaging and Monopulse Radar | |
| DP-CRF-6008 | Clock Synthesizer Module for Wind Profile Radar | |
| DP-CRF-6011 | Single channel IF1 Down Converter Module,1620/1630MHz,SMA Female connector | |
| DP-CRF-6014 | VHF Triple Channel, 20dB to 80dB Variable Gain Receiver Module for Wind Profile Radar | |
| DP-CRF-6017 | 7-way Power combiner / splitter module for VHF band | |
| DP-CRF-6020 | 13-way Power combiner / splitter module for VHF band | |
| DP-CRF-6026 | Microstrip patch array antenna for monopulse application,frequency 9.2GHz to 9.6GHz | |
| DP-CRF-6029 | Down Converter Receiver Module | |
| DP-CRF-6032 | VHF,144 to 148MHz, Telemetry receiver module | |
| DP-CRF-6035 | X4 Multiplier module (118.75-143.75 MHz to 475-575 MHz) | |
| DP-CRF-6038 | X band 80W 4 Way Quadrature Coupler Power Divider and Combiner | |
| DP-CRF-6041 | RF Filters LC BPF 26MHz 1dB BW 12MHz SMD | |
| DP-CRF-6044 | RF Filters LC BPF 39MHz 1dB BW 18MHz SMD | |
| DP-CRF-6047 | RF Filters LC BPF 59.5MHz 1dB BW 27MHz SMD | |
| DP-CRF-6050 | RF Filters LC BPF 92MHz 1dB BW 42MHz SMD | |
| DP-CRF-6053 | RF Filters LC BPF 144MHz 1dB BW 66MHz SMD | |
| DP-CRF-6056 | RF Filters LC BPF 227.5MHz 1dB BW 105MHz SMD | |
| DP-CRF-6059 | RF Filters LC BPF 358.5MHz 1dB BW 165MHz SMD | |
| DP-CRF-6062 | RF Filters LC BPF 570.5MHz 1dB BW 263MHz SMD | |
| DP-CRF-6065 | RF Filters LC BPF 850MHz 1dB BW 300MHz SMD | |
| DP-CRF-7004 | S-Band Dual Channel Analog Receiver | |
| DP-CRF-7007 | S Band Exciter Module for Ground based Applications | |
| DP-CRF-7010 | RES and channel selector module | |
| DP-CRF-7016 | Distributor Module | |
| DP-CRF-7025 | Local oscillator module for 540MHz and 50MHz signal generation | |
| DP-CRF-7034 | S-Band Up converter (2.7GHz-3.1GHz & 3.1GHz-3.5GHz) | |
| DP-CRF-7043 | Radar Environmental Simulator | |
| DP-CRF-7052 | Channel Selection Matrix Piggy Card | |
| DP-CRF-7055 | RF distribution box | |
| DP-CRF-7058 | Distribution Box | |
| DP-CRF-7061 | Array Group Analog Receiver | |
| DP-CRF-7061-630 | Eight channel Analog Receiver Module | |
| DP-CRF-7064 | Tx Drive Distribution Network | |
| DP-CRF-7067 | LO1 Distribution Network | |
| DP-CRF-7070 | LO2 & Noise Distribution network | |
| DP-CRF-7073 | L-Band-TRM receiver | |
| DP-CRF-7076 | DRM - Receiver board | |
| DP-CRF-7079 | GRF ATE | |
| DP-CRF-7082-303 | 25W C band Quad Channel Transmitter | |
| DP-CRF-7085 | C band 25W Transmitter Module | |
| DP-CRF-7088 | C band Front End Receiver Module | |
| DP-CRF-7091 | L Band 4 KW Transmitter Module | |
| DP-CRF-7094 | L Band 2.5 KW Transmitter Module | |
| DP-CRF-7097 | L Band 1.5 KW Transmitter Module | |
| DP-CRF-7100 | 500W Transmitter Module with Diversity Switch, 1090MHz | |
| DP-CRF-7103 | Frequency Synthesizer Module for Search Receiver | |
| DP-CRF-7106 | 3.5KW Transmitter Module for CIT | |
| DP-CRF-7109 | PLL Based LO2 Generation Module for Wide & Narrow Band RF Tuner | |
| DP-CRF-7112 | 500 Watts VHF Transmitter Module | |
| DP-CRF-7115 | VHF Receiver Module | |
| DP-CRF-7118 | 500 Watts VHF Transmitter Module-205MHz CF 5MHz BW | |
| DP-CRF-7121 | VHF Receiver and Power supply Module | |
| DP-CRF-7124 | V/UHF synthesizer Module of Search Receiver | |
| DP-CRF-7127 | 20 to 3000MHz V/UHF Tuner | |
| DP-CRF-7130 | C Band GaN Based 25Watts Quad Channel Transmitter Board | |
| DP-CRF-7133 | C Band Quad Channel Receiver Board | |
| DP-CRF-7136 | S Band GaN Based 100Watts Dual Channel Transmitter Board | |
| DP-CRF-7139 | S Band Dual Channel Receiver Board | |
| DP-CRF-7142 | 2kW Transmitter Module, 1030 MHz/ 1090 MHz, Pin:10dBm | |
| DP-CRF-8003 | 2KW IFF Pulsed Amplifier/Transmitter | |
| DP-CRF-8006 | L-Band-TRM transmitter | |
| DP-CRF-8009 | L-Band filter, 2W amplifier test board. | |
| DP-CRF-8012 | Transmitter Module for Transponder | |
| DP-CRF-8015 | L-Band IFF Receiver Module for TXP | |
| DP-CRF-8018 | 4KW transistor module | |
| DP-CRF-8021 | L-Band IFF Interrogator (Receiver Module) | |
| DP-CRF-8024 | Power Combiner, 3.1 to 3.5Ghz, 4 : 1, BMA Female inputs connectors, QMA Female output connector | |
| DP-CRF-8027 | 1KW L Band Transmitter Board for IFF using LDMOS Approach | |
| DP-CRF-8030 | 1KW Transmitter Test board for LDMOS Approach | |
| DP-CRF-8033 | 1 KW Power Amplifier Module | |
| DP-CRF-8036 | 4 K\W Power Amplifier Front End Module | |
| DP-CRF-8039 | 4 KW Power Combiner Module | |
| DP-CRF-8042 | 100Watts VHF Power Amplifier Module | |
| DP-CRF-8045 | 300Watts VHF Power Amplifier Module Pallet | |
| DP-CRF-8048 | VHF Power Amplifier Front End Controller Module | |
| DP-CRF-8051 | 4W V/UHF Wideband Driver Amplifier Module for Power Amplifier | |
| DP-CRF-8054 | Narrow Band VHF/UHF RF Tuner | |
| DP-CRF-8057 | Narrow band VHF/UHF RF Tuner (down converter) with Single 10.7MHz IF output | |
| DP-CRF-8060 | Front end module for U/VHF Narrow band tuner | |
| DP-CRF-8063 | Synthesizer for Wide Band Tuner | |
| DP-CRF-8066 | Synthesizer for Narrow Band Tuner | |
| DP-ECM-0411 | Wide Band Dual Directional Coupler | |
| DP-ECM-0600 | Wideband 1KW 45MHz Low pass filter Unit | |
| DP-ECM-0603 | Wideband 1KW 67MHz Low pass filter Unit | |
| DP-ECM-0606 | Wideband 1KW 103MHz Low pass filter Unit | |
| DP-ECM-0609 | Wideband 1KW 165MHz Low pass filter Unit | |
| DP-ECM-0612 | Wideband 1KW 285MHz Low pass filter Unit | |
| DP-ECM-0615 | Wideband 1KW 512MHz Low pass filter Unit | |
| DP-SSPA-5103-600 | 300W X Band Solid State Power Amplifier | |
| DP-TRM-8006 | 500W VHF Transmitter/Receiver Module | |
| DP-UDC-6701 | Airborne Ku Band Up Converter and L Band Down Converter | |
